NAD Hybrid Digital DAC Amplifier 2x30W

$599.00
people are viewing this right now

The NAD D 3020 V2 HybridDigital DAC Amplifier is a compact, modern amplifier that brings high-fidelity sound into everyday listening spaces. Delivering 30 watts per channel with NAD’s HybridDigital amplification and PowerDrive™, it offers clear, controlled performance across music, TV, and vinyl. A high-resolution DAC, Bluetooth with aptX, and versatile digital and analogue inputs ensure seamless connectivity. Thoughtful features like a built-in phono stage, Bass EQ, and subwoofer output make it an ideal, flexible solution for compact hi-fi or desktop systems.

Chat with our specialist

Available with Professional installation in NY, NJ, and CT – Powered by Sound Waves .

The NAD D 3020 V2 HybridDigital DAC Amplifier brings the spirit of the original NAD 3020 into a modern, compact design built for today’s listening habits.

With HybridDigital amplification, Bluetooth streaming, and versatile digital and analogue inputs, it delivers clear, engaging sound in smaller hi-fi and desktop systems.

Key Features

  • 30W per channel HybridDigital amplification with PowerDrive
  • 24-bit/192kHz DAC for high-resolution digital playback
  • Bluetooth with aptX for wireless streaming
  • Moving Magnet phono input with RIAA equalisation
  • Optical and coaxial digital inputs
  • Analogue line input for legacy sources
  • Pre-out for subwoofer or external amplification
  • Bass EQ and soft clipping for compact speaker optimisation
  • Efficient design with low standby power consumption
  • Award-winning compact amplifier design

Compact Design, Big Listening Experience

The D 3020 V2 fits easily into small hi-fi systems, desktops, and modern living spaces.

Despite its size, it delivers a full and engaging sound that enhances everyday listening.


Confident, Musical Power

With HybridDigital amplification and PowerDrive technology, the D 3020 V2 delivers controlled, expressive sound.

It maintains clarity and balance even with dynamic music and varying speaker loads.


Flexible Listening for Music and TV

Bluetooth streaming, digital inputs, and a phono stage allow easy switching between sources.

This makes it simple to enjoy music, vinyl, and TV sound within a single compact system.

Optimised for Smaller Systems

Features like Bass EQ and soft clipping improve performance with compact speakers.

Pre-out connectivity allows system expansion while maintaining flexibility.



Amplifier Performance

Rated power (8 Ω) 2 × 30 W
IHF dynamic power 8 Ω: 2 × 60 W
4 Ω: 2 × 100 W
2 Ω: 2 × 150 W
Signal-to-noise ratio ≥90 dB (A-weighted)
Channel separation ≥75 dB (1 kHz) / ≥65 dB (10 kHz)
Channel balance 0 ±0.3 dB
Frequency response 0 to -0.3 dB (20 Hz – 20 kHz)
Total harmonic distortion ≤0.005%
Intermodulation distortion SMPTE: 0.02% / CCIF: 0.003%
Maximum input level 5 V

Phono Input (MM)

Signal-to-noise ratio >82 dB (line) / >76 dB (MM cartridge)
Input sensitivity 1.15 mV
Maximum input signal >90 mVrms (1 kHz)
Frequency response ±0.3 dB (20 Hz – 20 kHz)

General

Standby power ≤0.5 W
Supported resolution Up to 24-bit / 192 kHz (digital input)

Dimensions & Weight

Dimensions (W × H × D) 58 × 186 × 219 mm
Net weight 1.38 kg (3.05 lbs)
Shipping weight 2.1 kg (4.6 lbs)
