ELAC 6.5″ In-Ceiling Subwoofer – Black

Name: ELAC 6.5" In-Ceiling Subwoofer - Black
Brand: ELAC
SKU: IC-VS6-B
Availability: InStock

$899.00

people are viewing this right now

The ELAC Vertex In-Ceiling Passive Subwoofer delivers powerful low-frequency reinforcement in a discreet architectural design that integrates seamlessly into modern interiors. Engineered to fit between standard ceiling joists, this passive bandpass subwoofer features a custom 6.5-inch dual voice coil driver capable of producing impressive bass performance from a remarkably compact enclosure. A flexible yet rigid port tube minimizes turbulence and unwanted port noise while allowing versatile installation options. Designed to pair perfectly with the Vertex IC-V31 in-ceiling speakers, its trim-out system supports both round and square grilles, enabling a clean visual match with contemporary small-aperture lighting. Ideal for distributed audio and home theatre applications, the Vertex In-Ceiling Passive Subwoofer provides impactful, well-balanced bass without compromising room aesthetics.

Chat with our specialist

Available with Professional installation in NY, NJ, and CT – Powered by Sound Waves .

Overview

This Vertex subwoofer is designed to fit between standard ceiling joists. The port coupling ring allows for the trim out to match ELAC’s IC-V31 speaker with either a roundor square grill. When matched with the IC-V31 speakers in a ceiling, the installation becomes complimentary with contemporary small aperture ceiling lights.

FLEXIBLE PORT TUBE

The port tube is flexible enough to allow versatile installation, but rigid enough to minimize wind turbulence which can result in port noise

6.5” DUAL VOICE COIL SPEAKER

The subwoofer includes a 6.5” dual voice coil subwooferto deliver an incredible amount of low frequency response in a small form factor. This subwoofer is sonically matched to the IC-V31 to create a balanced system, however, canbe used to compliment any speaker to reinforce low frequency response.

IN-CEILING SUBWOOFER

PASSIVE

Our in-ceiling subwoofer is designed to discreetly install ceiling joists and trim out to match small aperture lighting. Low frequencies are delivered by way of one 6” DVC woofer in a bandpass enclosure that vents out through a port opening. The end result is low frequency reinforcement in a form factor that works with interior design.

IN-CEILING SUBWOOFER

Grilles

Square grill and round grilles are available to cosmetically match lighting

Specifications

Speaker Specifications

Woofers	6.5-inch
Frequency Response (Subwoofer Section)	35 Hz - 125 Hz ±3 dB
Sensitivity	87 dB @ 2.83V/1m
Crossover	125 Hz @ 12 dB per octave
Impedance	6 Ohms Nominal
Frequency Response (System)	20 Hz - 20 kHz
Maximum Power Input	150 Watts
Height	9.06 in / 230 mm
Width	19.49 in / 495 mm
Depth	9.06 in / 230 mm
Flexible Port Tube Diameter	76.2 mm (3 in)
